在前端开发中经常需要一些过渡动画，可以借助SVG作为背景动画实现。

原文链接

animate

svg中animate元素可以用于实现动画效果

• attributeName

定义发生变化的元素属性名

• attributeType

当attributeType="XML"时，attributeName被认为是XML的属性；当attributeType="CSS"时，attributeName被认为是css的属性；不指定attributeType时，默认为"auto"，会先将attributeName作为css的属性，如果无效，再将attributeName作为XML的属性。

• from、to、by

from和to分别定义发生变化的属性的初始值和终止值。from可缺省，表示初始值即为animate父元素相应的属性值。可用by替换to，表示变化偏移量。可以理解为to = from + by。

• begin、dur、end

begin定义动画开始时间；dur定义动画所需时间；end定义动画终止时间。时间单位h：小时；min：分钟；s：秒；ms：毫秒。默认时间单位为：s

• fill

当fill="freeze"时，动画终止时，发生变化的元素属性值停留在动画终止时的状态；当fill="remove"时，动画终止时，发生变化的元素属性值回复到动画起始时的状态。fill属性默认值为：remove。

---

<rect x="10" y="10" width="200" height="20" stroke="green" fill="none"><animate attributeName="width" attributeType="XML"from="20" to="200" begin="0s" dur="3s" fill="freeze" />
</rect>

以上代码会实现一个绿色正方形逐渐拉长的动画。

animateTransform

实现transform属性改变的动画，使用animateTransform来替代animate元素。
animateTransform的attributeName指定为transform，用type属性指定需要改变的属性，如：translate，scale，rotate，skewX，skewY等。

animateTransform还有个additive属性。默认情况下additive属性值为replace，表示当前animateTransform的初始状态与之前的animateTransform变化结果无关，如果additive="sum"，表示当前animateTransform的变化基于之前的animateTransform变化之上。

<rect x="10" y="10" width="20" height="20" style="fill: #ff9; stroke: black;"><animateTransform id="a1" attributeName="transform" attributeType="XML" type="scale" from="1" to="4 2" additive="sum" begin="0s" dur="4s" fill="freeze"></animateTransform><animateTransform attributeName="transform" attributeType="XML" type="rotate" from="0" to="45" additive="sum" begin="a1.end" dur="4s" fill="freeze"></animateTransform>
</rect>

animateMotion

animateMotion可以实现单凭css动画属性无法实现的效果。
animateMotion可以让父元素沿着指定的路径运动，如：

<g><rect x="0" y="0" width="50" height="30" style="fill: #ccc;"/><circle cx="40" cy="30" r="10" style="fill: #fff; stroke: black;"/><circle cx="10" cy="30" r="10" style="fill: #fff; stroke: black;"/><animateMotion path="M50,125 C 100,25 150,225, 200, 125" dur="4s" fill="freeze"/>
</g>

animateMotion有个rotate属性，默认为0，元素在运动时不会旋转。当设置为auto时，元素对应的水平轴会始终与path路径保持水平。

loading效果


公共css

.loading {width: 100px;height: 100px;background-repeat: no-repeat;background-size: cover;
}

html

<div class="loading loading-audio"></div>
<div class="loading loading-ball-triangle"></div>
<div class="loading loading-bars"></div>
<div class="loading loading-circles"></div>
<div class="loading loading-grid"></div>
<div class="loading loading-oval"></div>
<div class="loading loading-puff"></div>
<div class="loading loading-spinning-circles"></div>
<div class="loading loading-tail-spin"></div>
<div class="loading loading-three-dots"></div>

css

}

效果
